DK Coding, Marks Each Moment
| Brand Name: | DIKAI |
|---|---|
| Model Number: | DLC130 |
| Minimum Order Quantity: | 1 |
| Price: | USD $ 5400-6900 / set |
| Packaging Details: | Carton Box |
| Delivery Time: | 15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 100 sets per month |
| Fonts: | 26 Languages, Multi - Language Support, Support User - Defined Fonts | Codes Support: | Barcode, QR-code |
|---|---|---|---|
| Document Type: | BMP/DXF/HPGL/JPEG | Print Area: | 50*50mm 70*70mm 110*110mm 140*140mm 175*175mm 210*210mm |
| Functions: | 10.1 Inch Touch Screen, Virtual Keyboard, Iconic Interface | ||
| Highlight: | 30w Barcode Overprinter,Leather Barcode Overprinter,Co2 Laser Coding Machine |
||
30w Co2 Laser Coding Machines For Plastic Bottle Cover/ Wood/ Cloth/ Metal/ Leather/ Cable
DLC130 has smaller size, lower maintenance, no consumables and provides permanent high-quality coding. Can be commonly used in food, cosmetics and other industries of flexible packaging, hard plastic (PE/PP), metal and other materials. It can print high contrast logo, to ensure the traceability of the product permanently.
High speed, high quality, high reliability
Faster coding speed, up to 200m/min
The new intelligent control algorithm provides high quality marking technology
Enhanced anti-electromagnetic design ensures stable operation in harsh environment
It can run 24 hours continuously
Ease of integration
Compact independent design, can be better integrated into the existing production line
Compact size, can adapt to a variety of installation space
Abundant identification information, permanent identification
Almost unlimited font, graphics and bar code applications
Permanent identification, the most reliable anti - counterfeiting string selection
Easy to operate and low maintenance, no consumables
Innovative interface is easy to learn and easy to understand, more convenient and fast operation
Efficient fan cooling design for low maintenance and high life
Average fault-free service up to 50000 hours
No consumables required
Technical Specifications:
| Model | DLC130 | ||
| Laser Type | CO2 Laser, wavelength=10.6μm, 10.2μm, 9.3μm,MTBF 50,000 hours | ||
| Laser Power | 30W | ||
| Features | |||
| Scan Speed | ≤12000mm/s | ||
| Speed | 200m/min | ||
| Lines | unlimited within marking area | ||
| Height | 0.80mm - max. marking area | ||
| Font | 26 fonts, multiple languages, custom fonts | ||
| Bar Codes | Code39/Code25/EAN-13/Code128, etc. | ||
| QR Codes | PDF147/QR CODE/DATAMATRIX | ||
| Graphic | DXF/PLT format vector image input/output | ||
| Variable | serial number, text, date, time, counter, shift code | ||
| Marking Area | 50*50, 70*70, 90*90, 110*110, 140*140, 175*175, 210*210, 250*250, ~500 mm | ||
| Focal Distance | 75, 100, 130, 150, 200, 250, 300, 355, 435, 585, 720mm | ||
| Functions | 10.1 inch Color Touch Screen, QWEERTY or AZERTY Virtual Keyboard, Quick Icon Wizard Operation, Online Help, Multi-Language, Ethernet Remote PC Operation |
||
| Materials | Anodised aluminium | ||
| Input/Output | |||
| Sensor | NPN / PNP /24V sensor or Triger Signal | ||
| Encoder | Encoder or synchronzing signal | ||
| Signal Input | Two way input, support custom | ||
| Signal Output | Three-way output, support custom | ||
| Communication | SD card/USB 2.0/Communication interface | ||
| Facilities Condition | |||
| Power Supply | 110-220V AC,50-60Hz | ||
| Cooling | Air Cooling | ||
| Environment | 5-40C,10%-90%RH,no-condensing | ||
| IP Rate | IP54 | ||
| Optional | Joint bar, Mounting bracket, Fume extractor | ||
* The quantity of characters printed each second and production line speed depends on the surface material and marking content.
