| Place of Origin: | China |
|---|---|
| Minimum Order Quantity: | 1 |
| Price: | $3,200-3,500 |
| Voltage: | AC100-240V 50/60Hz | Printhead Width: | 53mm |
|---|---|---|---|
| Printhead Resolution: | 300DPI | Print Area Intermittent: | 53*70mm |
| Print Area Continuous: | 53*150mm | Print Frequency: | ≤300times/min |
| Ribbon Length: | 600m | Ribbon Width: | 33mm~55mm |
| Power Consumption: | 150W | Operating Temperature: | 0-40℃ |
| Humidity Range: | 10%~95% (non-condensing) | Air Pressure: | 6bar/90psi |
| Print Unit Weight: | 9.5KG | Controller Box Weight: | 2.0KG |
| Print Unit Dimensions: | 210*210*180mm | ||
| Highlight: | AC100-240V Power Supply Thermal Transfer Overprinter,6bar Air Supply Smart Coding Machine,53x70mm Print Area TTO Printer |
||
| Specification | Details |
|---|---|
| Print Head | 53mm, Kyocera; 300DPI |
| Print Area | Intermittent: 53mm*70mm Continuous: 53mm*150mm |
| Ribbon Size | 55mm*600m |
| Print Frequency | Intermittent: up to 300PPM Continuous: up to 30PPM |
| Power | 150W |
| Operation Temperature | 0-40℃ |
| Relative Humidity | 10%~95% (non-condensing) |
| Air Supply | 6bar/90PSI (MAX) dry, Clean |
| Weight | Print head: 8.5kg, Control box: 2.0kg |
| Dimensions (L*W*H) | Print Unit: 210mm*210mm*185mm Controller box: 233mm*180mm*128mm |
